TRINOCULAR OBSERVATION HEAD
- Siedentopf observation head inclined at 45°.
- Vertical phototube for micro photography light split (80:20).
- Diopter adjustment ring on ocular tube (±5).
- Interpupillary distance from 52mm to 75mm.
EYEPIECE
- Wide field eyepiece 10X (Paired) FOV 22mm
OBJECTIVES (INFINITY CORRECTED, ANTIFUNGAL,Wide View)
- M Long Working Distance Plan Achromatic 10X
- M Long Working Distance Plan Achromatic 20X
- M Long Working Distance Plan Achromatic 50X
- M Long Working Distance Plan Achromatic 100X Dry
MECHANICAL BODY
- Co-axial focusing system with large knobs, PRE-FOCUSING LEVER & TENSION ADJUSTMENT RING.
- Quadruple nosepiece on ball bearing.
- Mechanical stage is 242mmX200mm
- The Mechanical stage has low positioned co-axial controls on ball bearing guide ways.
Polarizing Outfit
- Analyser rotatable at 360 degree . polarizer and analyser can be moved out of optical path
MECHANICAL BODY
- Co-axial focusing system with large knobs, PRE-FOCUSING LEVER & TENSION ADJUSTMENT RING.
- Quadruple nosepiece on ball bearing.
- Mechanical stage is 242mmX200mm
- The Mechanical stage has low positioned co-axial controls on ball bearing guide ways.
ILLUMINATOR
- The Epi-Koehler’s illuminator has 12V 100W halogen lamp adjustable brightness.
