MEASUREMENT- WELD PENETRATION ANALYSIS
- Spatial calibration
- Line measurements for distance, Length, Width, Perimeter, Area, Angle Three point radius.
- Area by enclosed line controlled by four arrow keys available on keyboard arrows with zoomed preview.
- COUNT AND CLASSIFICATION
- Identification of objects in an image, count them, obtain several features measurements like Length, Width, Area, Roundness etc. Objects identification by user or automatically. User defined classification on basis of size or intensity.
- Separation
- Separation of particles as Metallic, Non-metallic and fiber
- WELD or DIMENSIONAL MEASUREMENTS(2D)
- Manual, Auto bright and Auto dark methods to identify objects. Various calculation & measurements available for selected particle like Area, Perimeter, length, Width, Min Radius, Max Radius, Minor axis, Major Axis, Roundness, Shape, Orientation, Elongation, Diameter, Sphere volume etc.
- REPORT
- Own report tool no third party tool required. So easy to operate.
- Direct printout with original image processed image, Graph and results
- Saving with Sample Id or Heat No., so easy to find or open report.
